ATG A5 S Flying Probe Tester, used

ATG A5 S Flying Probe Tester





A5 Flying Probe Test System, Type: 726
Soft Touch version, 4 test probes per side
S/N 07/08 0A5S 073, Year of build: 2007

Basic unit with 8 test probes (4 top, 4 bottom), 4 cameras 2 top 2 bottom

Variable board mounting system, multi-board test
Max. board size (X x Y) 650 x 475 mm – 25.6″ x 18.7″
Test area (X x Y) 610 x 460 mm – 24.0″ x 18.0″
Board thickness up to 7 mm
Smallest pad 50 μm/ 2.0 mil
Smallest pitch 100 μm/ 4.0 mil
System accuracy :t20 μm/ :t 0.8 mil
Repeatability :t 10 μm/ :t 0.4 mil
Soft-touch probes 5 to 15 g/ leave no marks



We will be happy to provide you with information about price, installation and delivery conditions.

Please contact us without obligation by email:  olemotz(at)pcb-olitec.de
